LOCTITE® EA E-20HP
Features and Benefits
slide 1 of 4
Available sizes:
LOCTITE EA E-20HP is an off-white, 2-part, toughened, medium-viscosity, epoxy-based structural and magnet bonder with high impact and high humidity resistance.
LOCTITE® EA E-20HP is a high impact and humidity resistant structural bonder. The off-white, 2-part, toughened, medium-viscosity industrial grade epoxy adhesive is suitable for bonding surface and interior permanent magnets (IPM & SPM). It has a very high shear strength of 33 N/mm² and withstands high temperatures up to +150°C. It is resistant to a wide range of chemicals and solvents and is an excellent electrical insulator.
- High impact and high humidity resistance
- Designed for wide variety of substrates: e.g. plastics, metals and magnets (SPM and IPM)
- Temperature resistance up to +150°C
- Curing mechanism: RT, heat
- Viscoelastic & Finite Strain FEA data cards available
Documents and Downloads
Safety Data Sheets and RoHs
- Dual cartridge 10.0/case - IDH 237107
- Dual cartridge 10.0/case - IDH 237108
- Dual cartridge 6.0/case - IDH 237109
LOCTITE® EA E-20HP, 50 ml Dual cartridge 237107 en-CA
IDH:
237107
EAN:
079340293144
Size Case: Dual cartridge
Quantity: 10.0/case
LOCTITE® EA E-20HP, 200 ml Dual cartridge 237108 en-CA
IDH:
237108
EAN:
079340293151
Size Case: Dual cartridge
Quantity: 10.0/case
LOCTITE® EA E-20HP, 400 ml Dual cartridge 237109 en-CA
IDH:
237109
EAN:
079340293168
Size Case: Dual cartridge
Quantity: 6.0/case
Download SDS
LOCTITE EA E-20HP A RESIN IDH: 237109 EN/CA (1 of 4)
LOCTITE EA E-20HP A RESIN known as DB EPOXY ADH E-20HP 200ML RESIN IDH: 237109 EN/CA (2 of 4)
LOCTITE EA E-20HP B HARDENER IDH: 237109 EN/CA (3 of 4)
LOCTITE EA E-20HP B HARDENER known as DB EPOXY ADH E-20HP 200 ML HARD IDH: 237109 EN/CA (4 of 4)
Download RoHs
IDH: 237109 EN/CA (1 of 4)
IDH: 237109 EN/CA (2 of 4)
IDH: 237109 EN/CA (3 of 4)
IDH: 237109 EN/CA (4 of 4)
No documents found
Looking for a TDS or SDS in another language?
Additional Documents
Technical Information
| Application method | Dispense gun, Dispense system |
| Applications | Bonding metal, Bonding plastic |
| Cure type | Room temperature (ambient) cure, Two component mix |
| FEA (finite element analysis) | Finite strain, Viscoelastic |
| Key characteristics | Peel strength: high peel strength, Shear strength: high shear Strength, Toughened, Viscosity: medium viscosity, Work life: medium work life |
| Mix ratio, by volume | 2 : 1 |
| Mix ratio, by weight | 100 : 55 |
| Number of components | 2 part |
| Physical form | Liquid |
| Recommended for use with | Concrete, Metal, Metal: aluminium, Metal: steel, Metal: steel - stainless steel, Plastic, Polyamide (nylon), Polycarbonate, Wood |
| Mixed | |
| Color, Mixed | Off white |
| Specific gravity, Mixed @ 25.0 °C | 1.03 |
| Resin | |
| Color, Resin | Light yellow |
| Specific gravity, Resin @ 25.0 °C | 1.0 |
| Viscosity, Resin @ 25.0 °C | 40000.0 - 90000.0 mPa·s (cP) |
| Hardener | |
| Color, Hardener | Yellow |
| Specific gravity, Hardener @ 25.0 °C | 1.1 |
| Viscosity, Hardener @ 25.0 °C | 5500.0 - 8000.0 mPa·s (cP) |
LOCTITE® EA E-20HP
LOCTITE EA E-20HP is an off-white, 2-part, toughened, medium-viscosity, epoxy-based structural and magnet bonder with high impact and high humidity resistance.
